PRODUCTS

Brands Page

AlphaCast250


General Information
Category Gold
Caratage 14K-18K
Color White
Color Shade Standart White
Typology Alloys For Gold
Production Process İnvestment Casting
Density [cm3] 14,69
Solidus [°C] 875
Liquidus [°C] 925
As cast hardness [HV] 180
Ingredient
  • Ag
  • Cu
  • Zn
  • Ni
  • Deoxidant
  • Grain Refiner
  • Other
Typical Applications
Open System
Closed System
Sheet Production
General Characteristics
As Cast Grain Size [µm] 155
Color Coordinates
L* 86,3
a* 2,82
b* 13
c* 13,3
Mechanical Caracteristics
Tensile Strength (Rm) [MPa] 505
Yields strength (Rp0.2) [MPa] 350
Elongation Rupture (A) [%] 23
As cast Hardness [HV] 180
Hardness after 70% area red. [HV] 300
Hardness after annealing [HV] 190
Hardness after age-hardening [HV] 205
Casting Processing Parameters
Pre-mixing temperature [°C] 1100
Casting Temperatures Metal [°C] Flask [°C]
Thin (below 0.5 mm ) 1000 - 1030 660 - 720
Medium ( from 0.5-1.2 mm) 980 - 1000 620 - 660
Thick (Thick 1.2 mm) 960 - 980 540 - 620
After casting, cooling time for the flaks is 45 minutes.
After casting, cooling time for the flaks is 15 minutes.
Sulphuric acid (%10) - 5 min - 50°C
Age Hardening Processing Parameters
Single step age-hardening treatment Temperature [°C] Time [min] Quenching Age-hardening
Age-hardening 300 100 Cooling in furnuce
12 product in your basket.see product
  • Selected Products
Compare

Copyright © Alpha Plus

Web Tasarım
