PRODUCTS

Brands Page

AlphaCast025


General Information
Category Gold
Caratage 10-14K
Color White
Color Shade Standart White
Typology Alloys For Gold
Production Process İnvestment Casting
Density [cm3] 12.81
Solidus [°C] 800
Liquidus [°C] 890
As cast hardness [HV] 180
Ingredient
  • Ag
  • Cu
  • Zn
  • Ni
  • Deoxidant
  • Grain Refiner
  • Other
Typical Applications
Open System
Closed System
General Characteristics
As Cast Grain Size [µm]
Color Coordinates
L* 87
a* 1.73
b* 10.9
c* 11.03
Mechanical Caracteristics
Tensile Strength (Rm) [MPa] 528
Yields strength (Rp0.2) [MPa] 353
Elongation Rupture (A) [%] 45
As cast Hardness [HV] 180
Hardness after 70% area red. [HV]
Hardness after annealing [HV]
Hardness after age-hardening [HV] 254
Casting Processing Parameters
Pre-mixing temperature [°C] 1100
Casting Temperatures Metal [°C] Flask [°C]
Thin (below 0.5 mm ) 1020 - 1050 660 - 700
Medium ( from 0.5-1.2 mm) 1000 - 1020 620 - 660
Thick (Thick 1.2 mm) 980 - 1000 580 - 620
After casting, cooling time for the flaks is 45 minutes.
After casting, cooling time for the flaks is 15 minutes.
Sulphuric acid (%10) - 5 min - 50°C
Age Hardening Processing Parameters
Single step age-hardening treatment Temperature [°C] Time [min] Quenching Age-hardening
Age-hardening 285 100 Cooling in furnuce
12 product in your basket.see product
  • Selected Products
Compare

Copyright © Alpha Plus

Web Tasarım
