AlphaRoyal1850


General Information
Category Gold
Caratage 18K
Color Yellow
Color Shade Arabic Yellow
Typology Alloys For Gold
Production Process İnvestment Casting
Density [cm3] 15,1
Solidus [°C] 830
Liquidus [°C] 900
As cast hardness [HV] 134
Ingredient
  • Ag
  • Cu
  • Zn
  • Ni
  • Deoxidant
  • Grain Refiner
  • Other
Typical Applications
General Characteristics
As Cast Grain Size [µm] 400
Color Coordinates
L* 89,7
a* 2,1
b* 23,5
c* 23,6
Mechanical Caracteristics
Tensile Strength (Rm) [MPa] 350
Yields strength (Rp0.2) [MPa] 230
Elongation Rupture (A) [%] 40
As cast Hardness [HV] 134
Hardness after 70% area red. [HV] 260
Hardness after annealing [HV] 145
Hardness after age-hardening [HV] 230
Casting Processing Parameters
Pre-mixing temperature [°C] 1080
Casting Temperatures Metal [°C] Flask [°C]
Thin (below 0.5 mm ) 1020 - 1060 660 - 720
Medium ( from 0.5-1.2 mm) 990 - 1020 600 - 660
Thick (Thick 1.2 mm) 970 - 990 540 - 600
After casting, cooling time for the flaks is 15 m
After casting, cooling time for the flaks is 45 m
Sulphuric acid (%10) - 5 min - 50°C
Age Hardening Processing Parameters
Single step age-hardening treatment Temperature [°C] Time [min] Quenching Age-hardening
Age-hardening 275 100 Cooling in furnuce
