PRODUCTS

AlphaCast240


General Information
Category Gold
Caratage 14K-18K
Color White
Color Shade Standart White
Typology Alloys For Gold
Production Process İnvestment Casting
Density [cm3] 12,756
Solidus [°C] 930
Liquidus [°C] 970
As cast hardness [HV] 170
Ingredient
  • Ag
  • Cu
  • Zn
  • Ni
  • Deoxidant
  • Grain Refiner
  • Other
Typical Applications
Open System
Closed System
Sheet Production
General Characteristics
As Cast Grain Size [µm] 170
Color Coordinates
L* 87,35
a* 1,53
b* 9,51
c* 9,63
Mechanical Caracteristics
Tensile Strength (Rm) [MPa] 512
Yields strength (Rp0.2) [MPa] 225
Elongation Rupture (A) [%] 55
As cast Hardness [HV] 170
Hardness after 70% area red. [HV] 290
Hardness after annealing [HV] 180
Hardness after age-hardening [HV] 190
Casting Processing Parameters
Pre-mixing temperature [°C] 1100
Casting Temperatures Metal [°C] Flask [°C]
Thin (below 0.5 mm ) 1040 - 1080 660 - 720
Medium ( from 0.5-1.2 mm) 1020 - 1040 620 - 660
Thick (Thick 1.2 mm) 1000 - 1020 540 - 620
After casting, cooling time for the flaks is 45 minutes.
After casting, cooling time for the flaks is 15 minutes.
Sulphuric acid (%10) - 5 min - 50°C
Age Hardening Processing Parameters
Single step age-hardening treatment Temperature [°C] Time [min] Quenching Age-hardening
Age-hardening 285 100 Cooling in furnuce
12 product in your basket.see product
  • Selected Products

Copyright © Alpha Plus

Web Tasarım
